Old US-266 over Deek Fork River
In service 1933–2005 (72 yrs)
Closed to traffic
Through Truss
Old US-266 over Deek Fork River
Through Truss
Built 1933
210.00 ft
Built
1933
Type
Through Truss
Style
K-Parker
Length
210.00 ft
Main span
210.00 ft
Spans
1
Builder
Pharoah Co.
Visits
1
About
10-Panel K-Parker 210ft through truss
Built in 1933 and bypassed in 2005, this fine example of a standard OSHD 210' K Truss design (D-210) with a 24' wide roadway. Nothing really too historic as this type was built en masse on the state highway system. But is notable that it was left in place and not removed.
Built in 1933 and bypassed in 2005, this fine example of a standard OSHD 210' K Truss design (D-210) with a 24' wide roadway. Nothing really too historic as this type was built en masse on the state highway system. But is notable that it was left in place and not removed.
Identity & location
- NBI Number
- 040790000000000
- Carries
- Old US-266
- Crosses
- Deek Fork River
- Year Built
- 1933
- Year Closed
- 2005
Structure
1 × 210.00ft K-Parker Through Truss span (10 panels)
- Bridge Type
- Through Truss
- Main Span Style
- K-Parker
- Builder
- Pharoah Co.
- Connections
- Riveted
- Overall Length
- 210.00 ft
- Main Span Length
- 210.00 ft
- Deck Width
- 23.90 ft
- Clearance
- 15.90 ft
- Main Spans
- 1
- Main Span Panels
- 10
Span diagram
Direction: Unknown
210.00'
| # | Type | Style | Length | Panels | Role |
|---|---|---|---|---|---|
| 1 | Through Truss | K-Parker | 210.00 ft | 10 | Main |
Photos · 55
Unattached photos
Visit log · 1
-
Jun 29, 2024by Mike Roquemore
Appears in datasets
ODOT On System Bridges NBI
Survey data vs. current bridge record
| Field | Survey | Bridge | |
|---|---|---|---|
| NBI No | 04079 | 040790000000000 | ✗ |
| Structure No | 5612R0480 X | — | ⚠ |
| ODOT BRKEY | 4079 | — | ⚠ |
| Facility Carried | U.S. 266 | Old US-266 | ✗ |
| Feature | DEEP FORK RIVER | Deek Fork River | ✗ |
| Alt Name | 5612R0480 X | — | ⚠ |
| Description | 210ft. HIGH TRUSS & 3-60ft. I-BM. SPANS | 10-Panel K-Parker 210ft through truss Built in 1933 and bypassed in 2005, this fine example of a standard OSHD 210' K Truss design (D-210) with a 24' wide roadway. Nothing really too historic as this type was built en masse on the state highway system. But is notable that it was left in place and not removed. | ✗ |
| Year Built | 1933 | 1933 | ✓ |
| Latitude | 35.45 | 35.4782778 | ✗ |
| Longitude | -96.08333333 | -95.8831667 | ✗ |
| Overall Length | 395.013 | 210.00 | ✗ |
| Deck Width | 27.001 | 23.90 | ✗ |
| Main Spans | 1 | 1 | ✓ |
| Skew | 0 | — | ⚠ |
| Lanes | 2 | — | ⚠ |
| Road Width | 23.999 | — | ⚠ |
| Material | 3 - Steel | — | ⚠ |
| Design | 10 | — | ⚠ |
| Span Type Main | M | — | ⚠ |
| Deck Structure | 1 | — | ⚠ |
| Open / Closed | P | — | ⚠ |
| Sufficiency | 3 | — | ⚠ |
| Structure Rating | 3 | — | ⚠ |
| Deck Rating | 2 | — | ⚠ |
| Super Rating | 3 | — | ⚠ |
| Sub Rating | 6 | — | ⚠ |
| Culvert Rating | N | — | ⚠ |
| Owner | 01 - State Highway Agency | — | ⚠ |
| Custodian | 01 - State Highway Agency | — | ⚠ |
| Hwy System | 1 - On Highway | — | ⚠ |
| Functional Class | 07 - Major Collector (Rural) | — | ⚠ |
| Bridge System | C | — | ⚠ |
| ADT | 1500 | — | ⚠ |
| ADT Year | 2004 | — | ⚠ |
| Historical | 2 | — | ⚠ |
Source: Oklahoma Department of Transportation (ArcGIS / NBI) · Imported May 5, 2026
