Old SH-20 over Sycamore Creek
In service since 1930 (96 yrs)
Pony Truss
Old SH-20 over Sycamore Creek
Pony Truss
Built 1930
Built
1930
Type
Pony Truss
Style
Warren
Visits
1
Identity & location
- NBI Number
- 030440000000000
- Carries
- Old SH-20 / 5320 Rd
- Crosses
- Sycamore Creek
- Year Built
- 1930
Structure
Warren Pony Truss
- Bridge Type
- Pony Truss
- Main Span Style
- Warren
Photos · 10
Unattached photos
Visit log · 1
-
Aug 14, 2024by Mike Roquemore
Appears in datasets
ODOT Off System Bridges NBI
Survey data vs. current bridge record
| Field | Survey | Bridge | |
|---|---|---|---|
| NBI No | 03044 | 03044 | ✓ |
| Structure No | 57E0390N3580009 | — | ⚠ |
| ODOT BRKEY | 3044 | — | ⚠ |
| County | Osage | Osage | ✓ |
| Facility Carried | 5740C | Old SH-20 / 5320 Rd | ✗ |
| Feature | SYCAMORE CREEK | Sycamore Creek | ✓ |
| Alt Name | 57E0390N3580008 | — | ⚠ |
| Description | 60ft. PONY TRUSS SPAN | — | ⚠ |
| Year Built | 1930 | 1930 | ✓ |
| Latitude | 36.4494 | 36.4494444 | ✗ |
| Longitude | -96.603278 | -96.6031389 | ✗ |
| Overall Length | 62.992 | — | ⚠ |
| Deck Width | 18.373 | — | ⚠ |
| Main Spans | 1 | — | ⚠ |
| Skew | 0 | — | ⚠ |
| Lanes | 2 | — | ⚠ |
| Road Width | 17.388 | — | ⚠ |
| Material | 3 - Steel | — | ⚠ |
| Design | Truss — Thru (10) | — | ⚠ |
| Span Type Main | Main span (M) | — | ⚠ |
| Deck Structure | Concrete cast-in-place (1) | — | ⚠ |
| Open / Closed | Posted for load (P) | — | ⚠ |
| Sufficiency | 28.9 | — | ⚠ |
| Structure Rating | Critical (2) | — | ⚠ |
| Deck Rating | Fair (5) | — | ⚠ |
| Super Rating | Fair (5) | — | ⚠ |
| Sub Rating | Fair (5) | — | ⚠ |
| Culvert Rating | Not applicable (N) | — | ⚠ |
| Owner | 02 - County Highway Agency | — | ⚠ |
| Custodian | 02 - County Highway Agency | — | ⚠ |
| Hwy System | 0 - Off Highway | — | ⚠ |
| Functional Class | 09 - Local (Rural) | — | ⚠ |
| Bridge System | D | — | ⚠ |
| ADT | 50 | — | ⚠ |
| ADT Year | 2022 | — | ⚠ |
| Historical | 4 | — | ⚠ |
Source: Oklahoma Department of Transportation (ArcGIS / NBI) · Imported May 6, 2026
